Grandstream GWN7670WM Wi-Fi 7 Dual-band 3.6Gbps Indoor Wall-mount Access Point with 2x2:2 MIMO, DL/UL OFDMA Technology and PoE+

Κωδικός Cableworks: 1075.128

The GWN7670WM is a new generation enterprise-grade in-wall Wi-Fi 7 access point, ideal for small-to-medium-sized businesses to build next-generation Wi-Fi networks. It has a stylish appearance and a sprayable shell, which easily matches various decoration styles and perfectly integrates into the space. It offers dual-band 2x2:2 MIMO with DL/UL OFDMA technology and a sophisticated antenna design for maximum network throughput and expanded Wi-Fi coverage range. Furthermore, improves bandwidth utilization and anti-interference ability with Multi-RU and Preamble Puncturing technology. With 4096 QAM modulation, Wi-Fi 7 achieves a significant increase in data transfer rates. MLO technology optimizes spectrum resource utilization to ensure a smooth experience for every user. To ensure easy installation and management, the GWN7670WM uses a controller-less distributed network management design in which the controller is embedded within the product’s Web user interface. Also supported by GDMS Networking and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platform. It is the ideal Wi-Fi AP for voice over-Wi-Fi deployments and offers a seamless connection with Grandstream’s Wi-Fi capable IP phones. With support for advanced QoS, low-latency real- time applications, mesh networks, captive portals, BT location with BLE 5.3, 256 concurrent clients per AP and 1x 2.5 Gigabit network ports with PoE+, GWN7670WM is an ideal Wi-Fi access point for wireless network deployments with medium-to-high user density.

Key Features & Benefits:

• 3.6Gbps aggregate wireless throughput, 2.5Gbps aggregate wired throughput
• Integrated Wi-Fi 7 & 2x2:2 MIMO with MLO, 4KQAM, MRU, Preamble Puncturing Technology
• Up to 175-meter coverage range
• Supports 256 concurrent Wi-Fi client devices
• Advanced QoS to ensure real-time performance of low-latency applications
• Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
• Self-power adaptation upon auto-detection of PoE+
• Embedded controller manages up to 50 local GWN APs
• GDMS Networking offers unlimited AP management, & GWN Manager offers on-premise software AP management
• 3 Year warranty

Specifications:

• Wi-Fi Standards: IEEE 802.11 a/b/g/n/ac/ax/be
• Antennas:
  - 5 single frequency antennas
  - 2.4GHz x 2, gain 3.0dBi
  - 5GHz x 2, gain 4.0dBi
  - BT gain 3.0dB
• Wi-Fi Data Rates:
  - 5G:
  - IEEE 802.11be: Up to 2882 Mbps
  - IEEE 802.11ax: 7.3 Mbps to 2402 Mbps
  - IEEE 802.11ac: 6.5 Mbps to 1732 Mbps
  - IEEE 802.11n: 6.5 Mbps to 300 Mbps
  - IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• - 2.4G:
  - IEEE 802.11be: Up to 688 Mbps
  - IEEE 802.11ax: 7.3 Mbps to 574 Mbps
  - IEEE 802.11n: 6.5Mbps to 300Mbps
  - IEEE 802.11b: 1, 2, 5.5, 11 Mbps
  - IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• Frequency Bands:
  - 2.4GHz Radio: 2400 - 2483.5 MHz
  - 5GHz Radio: 5150 - 5895 MHz
• Channel Bandwidth:
  - 2.4G: 20 and 40 MHz
  - 5G: 20, 40, 80, and 160 MHz
• Wi-Fi and System Security:
  - WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES)
  - WPA3, anti-hacking secure boot and critical data/control lockdown via digital signatures
  - Unique security certificate and random default password per device
• MIMO:
  - 2x2:2 2.4GHz
  - 2x2:2 5GHz
• Coverage Range:  Up to 175 meters
• Maximum TX Power:
  - 5G: 26dBm
  - 2.4G: 26dBm
• SSIDs: 32 SSIDs total, 16 per radio (2.4GHz & 5GHz)
• Concurrent Clients: 256
• Network Interfaces: 1x 2.5G Ethernet WAN/LAN
• Auxiliary Ports: 1x Reset Pinhole
• Bluetooth®: BLE 5.3
• Mounting: Indoor wall mount, kits included
• LEDs: 1 tri-color LED for device tracking and status indication
• Network Protocols: IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
• QoS: 802.11e/WMM, VLAN, TOS
• Network Management:
  - Embedded controller can manage up to 50 local GWN APs
  - GDMS Networking offers a free cloud management platform for unlimited GWN APs
  - GWN Manager offers premise-based software controller for up to 3,000 GWN APs
• Power & Green Energy Efficiency:
  - PoE/PoE+ 802.3af/at;
  - Maximum Power Consumption: 15.5W
• Environmental:
  - Operation: 0°C to 45°C
  - Storage: -30°C to 60°C
  - Humidity: 10% to 90% Non-condensing
• Physical:
• Unit Dimensions: 150 x 106 x 34.1 mm
• Unit Weight: 0.473 kg
• Package Dimensions: 193 x 138.5 x 54 mm
• Package Weight: 0.600 kg
• Package Contents:
  - GWN7670WM Wi-Fi 7 Wireless AP
  - Mounting Kits
  - Quick Start Guide
• Compliance: FCC, CE, RCM, IC
